UKUCILILA NO. |
UMULEMBO WA KUFWILISHA |
PANTU ABA PANO |
INSHILA |
||||||
|
DN |
UKUBUTUKA |
A |
C |
D |
H |
L |
|||
|
87391-08-08 |
1/2" |
12 |
08 |
41 |
30.2 |
24 |
47 |
6.73 |
|
|
87391-12-08 |
3/4" |
12 |
08 |
41 |
38.1 |
31.7 |
48 |
6.73 |
|
|
87391-12-10 |
3/4" |
16 |
10 |
56.5 |
38.1 |
31.7 |
52.5 |
6.73 |
|
|
87391-12-12 |
3/4" |
20 |
12 |
66.2 |
38.1 |
31.7 |
62 |
6.73 |
|
|
87391-12-12(H100) |
3/4" |
20 |
12 |
65.5 |
38.1 |
31.7 |
100 |
6.73 |
|
|
87391-12-12(H127) |
3/4" |
20 |
12 |
65.5 |
38.1 |
31.7 |
127 |
6.73 |
|
|
87391-12-12(H150) |
3/4" |
20 |
12 |
65.5 |
38.1 |
31.7 |
150 |
6.73 |
|
|
87391-12-16 |
3/4" |
25 |
16 |
76.7 |
38.1 |
31.7 |
67.5 |
6.73 |
|
|
87391-16-12 |
1" |
20 |
12 |
66.2 |
44.4 |
38 |
62 |
8 |
|
|
87391-16-16 |
1" |
25 |
16 |
78 |
44.4 |
38 |
67.5 |
8 |
|
|
87391-16-16(H100) |
1" |
25 |
16 |
76.7 |
44.4 |
38 |
100 |
8 |
|
|
87391-16-16(H127) |
1" |
25 |
16 |
76.7 |
44.4 |
38 |
127 |
8 |
|
|
87391-16-16(H150) |
1" |
25 |
16 |
76.7 |
44.4 |
38 |
150 |
8 |
|
|
87391-16-20 |
1" |
32 |
20 |
91.5 |
44.4 |
38 |
78.5 |
8 |
|
|
87391-20-16 |
1.1/4" |
25 |
16 |
78 |
50.8 |
43 |
67.5 |
8 |
|
|
87391-20-20 |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
78.5 |
8 |
|
|
87391-20-20(H100) |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
100 |
8 |
|
|
87391-20-20(H127) |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
127 |
8 |
|
|
87391-20-20(H150) |
1.1/4" |
32 |
20 |
91.5 |
50.8 |
43 |
150 |
8 |
|
|
87391-20-24 |
1.1/4" |
40 |
24 |
108.5 |
50.8 |
43 |
78.5 |
8 |
|
|
87391-24-20 |
1.1/2" |
32 |
20 |
91.5 |
60.3 |
50 |
80.5 |
8 |
|
|
87391-24-24 |
1.1/2" |
40 |
24 |
109.4 |
60.3 |
50 |
94 |
8 |
|
|
87391-24-24(H127) |
1.1/2" |
40 |
24 |
109.4 |
60.3 |
50 |
127 |
8 |
|
|
87391-32-24 |
2" |
40 |
24 |
109.4 |
71.4 |
62 |
94 |
9.53 |
|
|
87391-32-32 |
2" |
50 |
32 |
131.8 |
71.4 |
62 |
114.3 |
9.53 |
|
|
87391-40-32 |
2.1/2" |
50 |
32 |
131.8 |
84.1 |
74.4 |
114.3 |
9.53 |
|
Ifipimo/Ifyebo fya fyakupangapanga
|
Kubalilapo |
ZheJug, China |
Ubushiku bwakutumina |
Ukusuminishanya |
|
Ukushininkisha |
290001:2015. |
Ukupika |
imitantikile ya kutuma ku nse |
|
Ifya kubomfya |
Icipe ca Carbon |
ukusela |
umwaka umo |
|
Inshita ya kulipila |
Tte. T |
shimapepo |
2000 |
|
Umubele |
Icipya |
Ilangi |
zinc iyabuuta, ilangi zinc |
Pa lwa kampani
Abatungulula
Ukuputula-Lalani Ukucincimuka Ukucincimusha
Abatendeke ukushipikisha ukufika kuli 15,000 ukubomba umulimo wa kucincimusha
40% ukucila pa cipimo ca kucincimusha ukucila pa fipimo fya makwebo
Ukupatikisha ukwabikwa bwinokwetemocitile {0} ukukuma ku fya sayansi pa mibele yabipisha
Ukulungika Ukwalinga
CNC ukubomfya ±0.001" ukukongama kwa kushipikisha
100% ukushininkisha kwa mashini ya kupiminako (CMM) ukushininkisha
Ukuceeceeta kwa menso ukwaibela ukwa kupwisha ukwafikapo ukwa pa muulu
Sayansi ya pa muulu
Iciputulwa ca mu muludicitile(0000)} cilafumyapo amaka ya kulesha ukunaka
Ukubola kwa fipe fya {
Ukukongama kwa fipe fyonse ukufuma pa nshi ya ng’anda ukufika ku kupwisha ukupanga
icifulo(0}} ica bucibusa.
Lyonse tulabomfya imiti ya cifyalilwa ne miti nga ifipe, ukwabula ukupanga nelyo ukubomfya amakemiko, icintu ica cifyalilwa, icifulo(00)} ica bucibusa kabili ica musango usuma. Peela ing’anda yobe ukukumya bwino no mupashi
Ukushipikisha ukwabula ukulingana
Lyonse tulabomfya imiti ya cifyalilwa ne miti nga ifipe, ukwabula ukupanga nelyo ukubomfya amakemiko, icintu ica cifyalilwa, icifulo(00)} ica bucibusa kabili ica musango usuma. Peela ing’anda yobe ukukumya bwino no mupashi
Ukukonka Amafunde ayapwililika
Ukushininkishiwa kuli SAE, ISO, BUSHIKU, na ASME .
PEED, ATEX, na API 6A ifya kusalapo ifyakonkapo
ABS/DNV ukusuminisha kwa muli bemba ukwasangwa
Ifyakubikapo ifyakubikamo
Ilangi {0{0}} ukupangwa na kabungwe kapatikisha pakuti baishibikwe bwangu
Mukwangufyanya{0}} lungamika imipangile na 60% ukubika bwangu
Ifilangililo fya mubili ifyabikwa pamo ifya kulonganika bwino
Amabuumba ya Isubilo ya Kupanga
Ukupwisha amasuko ukufuma pali 1/8" ukufika kuli 6" ubukulu
Ifintu ifya kusekesha ukubikapo na Monda, Inkonto, na Setela
CAD {0{0}} ukulinganishiwa imipangile ya cifyalilwa
Ukushininkisha Kwacincimuka ukwa Busanso
100% ukufwailisha kwa menshi pa 1.5X ukubomba
Ukuceceta kwa fipimfya ifya mukuba ne fya magrean
Ifingi(0{li- ukukonkomesha ukupanga no kuceceta fyonse
Ubwafwilisho bwa fyakupangapanga ifya calo conse
24/7 ubwafwilisho bwa bu injiniya
Patwebe ukupitulukamo kwa mibombele ukwasangwa
Ukusambilisha kwa cine cine ukwa kubika
FAQ
Icipusho: Ni fipimo nshi ifya mu menshi ne fya kufwala fya mu menshi filakonka?
A: Ifipe fyesu filafikilisha ifipimo fya fya makwebo ifya calo conse, ukusanshako:
SAE J514, J518, J1453
ISO 8434, 6162, 12151
2353, 2006
INSHILA B16.5.5, B16.47
ANSI, NFPA, na API iyalungama
Icipusho: Ni mibele nshi iya kucincimusha iyasangwa?
A: Tulapeela ifya kufwala ne fya kufwala ifya misango yalekanalekana iya kucincimusha:
Ukucepa(Icipimo cacepako (Icacepako nelyo ukulingana na 3,000 PSI / 207 umusango) – Inshila sha menshi iyalinga
Icilinganishiwekwetemo (0,0,0,0,0,000,000 / 207-414) – Amanshi ya matekinoloji na aya mafoni
Iciputulwa ca nshita ica pa muulu (6,000-15,000,000 / 414-1,034) – Amafuta & umulilo, ifya mu lwelele, na mashini iyafina
Icipusho: Ni finshi ifibomfiwa mu fipe fyenu ifya kufwala ne fya kufwala?
A: Ifintu ifisangwa muli:
Umulongo wa Carbon – Zinc(000)}nika nangu ukutuntuka[11)
Icipe icabula amaka (304/316) – Ukukowela{2}} ukukandwa ku fifulo fyakosa
Iciputulwa ca nshita (ARISII 4130, 4140) – Icikulukwetemo(2)} amaka ya kucincimusha nga nshi
Amaboko ya ku nse (Imisango, Indalama, Titanium) – Pa mulandu wa kukaana kwa kemikali/umubili .
Icipusho: Kuti nasala shani ukulingana kwalinga nelyo ukwalinga pa nshita yandi?
A: Ifishinka fikalamba ifya kutontonkanyapo:
Umusango wa cimuti (NPT, BSPP, BSPT, Ifyakupangapanga, ORFS, na fimbi)
Ukukula (1/8" ukufika kuli 6")
Ukupima kwakwesha
Ukulingana kwa menshi
Imibele ya cifulo (ukutenta, ukubola, ukutenteka)
Ba injiniya besu balapeela ukwafwilisha kwa kusalapo ukwabula ukulipilisha.
Icipusho: Bushe ifya kufwala fyenu ifipilibulwa ne fishibilo fimbi?
A: Ee – Ifyakupangapanga fyesu fyapangilwe ku kwalula fyonse na SAE/ISO/DIN {0{0 ifipimo fya kusunga.
Ishiba: Lyonse shininkisha umusango wa nsonsela no kufimba pa kuti fibe ifyalinga.
Icipusho: Ni nshila nshi sha kufimbilikisha ishisangwa?
A: Tulapeela ifyakusalapo ifingi ifyakucingilila:
O{0{0}}Icakumwenako Ukulosha (OOFS) – Icisuma pa muulu{1}} ukukakatika, ukupongolwela(2}} ubushininkisho bwa kulungatika
Icilangililo ca Ndalama (NPT, BSPT) – Impendwa(0}}to- ukulingana na {1} ukufunga
Iciputulwa ca ku nse ne Cifulo ca Kufumbatika (SAE/SISO) – Pa kulundanya kwa flange .
Icishibilo ca {0[000)Ukupwa (IDIN 2353) – Ukukalipa(2 {2} ukushintilila pa kufunga
Icipusho: Ni nshita nshi iya kutungulula ku ma oda ya cifyalilwa vs.?
A: Ifipimo ifyalinga: inshiku 1-3 (mu cipe)
Amafunde/Imibele ya pa lwakwe: imilungu 2-4 (ukulingana no bwafya)
Imilimo Iikalamba: Ukusangwa ku fyakufwaikwa ifya bwangu
Icipusho: Bushe mulepeela ubutungulushi bwa kubika?
A: Ee. Tulapeela:
Intanshikwetemo(000)}} muli ifi fitabo fyakubikamo ifyakubikamo
Ifyakupilibula ifya pa muulu & ifyakukonkana ifya kukakatika
Amasambililo ya pa vidyo na 3D ifya kutungulula ifya 3D
Patwebe ukwafwilisha kwa ba tekinoloji (ukufwaya)
Icipusho: Ni fitupa nshi ifyo mwakwata?
A: Ififulo fyesu ne fipe fyashininkishiwa:
ISO 9001:2015 (Ukutungulula Ubusuma)
PEED 2014/SU 68/EU (Ifunde lya Fibombelo fya Kushininkisha)
ATEX (Amafunde ya Kukonkapo)
ABS, DNV, na Lloyd iya Kulembesha (Ifya Kubomfya Ifya Busanso)
Icipusho: Ni shani fintu ukusakamana kwakabilwa ku fya kufwala fya menshi?
A: Ukusakamana ukwasuminishiwa kuli:
Amacheki aya pa mwaka
Ukubikwa kwa cishibilo ca miceele
Ukuceceta kwa kumona pa lwa kubola/ ukufwala
Ukupima kwa mumbali ukwa mibombele ya pa muuludi iya pa muulu{0}} iya kucincimusha
